桥机规格 |
260t/50m |
220t/50m |
200t/50m |
200t/40m |
180t/40m |
160t/40m |
140t/40m |
120t/30m |
100t/30m |
60t/20m |
40t/20m |
起重量 |
130t+130t |
110t+110t |
100t+100t |
100t+100t |
90t+90t |
80t+80t |
70t+70t |
60t+60t |
50t+50t |
30t+30t |
20t+20t |
起升速度 |
0.59m/min |
0.68m/min |
0.79m/min |
0.79m/min |
0.5m/min |
0.65m/min |
0.65m/min |
0.75m/min |
0.9m/min |
1.55m/min |
1.93m/min |
横移速度 |
3m/min |
3m/min |
3m/min |
3m/min |
3m/min |
3m/min |
3m/min |
3m/min |
3m/min |
6.4m/min |
6.4m/min |
纵移速度 |
3m/min |
3m/min |
3m/min |
3m/min |
3m/min |
3m/min |
3m/min |
3m/min |
3m/min |
6.4m/min |
6.4m/min |
过孔速度 |
3m/min |
3m/min |
3m/min |
3m/min |
3m/min |
3m/min |
3m/min |
3m/min |
3m/min |
6.4m/min |
6.4m/min |
整机功率 |
80Kw |
80Kw |
80Kw |
80Kw |
80Kw |
65.2Kw |
65.2Kw |
54Kw |
54Kw |
28.5Kw |
28.5Kw |
适用坡度 |
纵坡≤5%,横坡≤5% |
||||||||||
外形尺寸 |
87(81)m×8m×9.5m |
66m×7.8m×9m |
52(48)m×7.5m×8.5m |
35m×5.5m×6m |
|||||||
适用斜桥 |
0°~ 45° |
||||||||||
适用弯桥 |
R≤350m |
R≤300m |
R≤200m |
R≤150m |
|||||||
整机重量 |
245t |
210t |
200t |
180t |
170t |
155t |
145t |
120t |
110t |
60t |
50t |
